Used Heavy Rigid Dump Truck For380HP
Available heavy-truck platforms include established brands such as HOWO, SHACMAN, SINOTRUK and FAW, subject to current vehicle availability. The trucks are sourced and assessed according to their actual condition rather than presented with a fixed specification that applies to every used unit.
Used 6×4 and 8×4 rigid dump trucks for construction, quarrying, earthmoving and bulk-material transport.
Available heavy-truck platforms include established brands such as HOWO, SHACMAN, SINOTRUK and FAW, subject to current vehicle availability. The trucks are sourced and assessed according to their actual condition rather than presented with a fixed specification that applies to every used unit.
Available vehicle information can include manufacturing year, mileage, engine model, rated power, transmission, drive configuration, dump-body dimensions, axle configuration, emission standard, tire condition and maintenance status.
Product Specifications
|
Parameter Category |
Baseline Technical Specification Range |
|
Drive Configuration |
6×4 (Three-axle) / 8×4 (Four-axle steer-drive) |
|
Gross Vehicle Weight (GVW) |
25,000 kg (6×4) to 32,000 – 40,000 kg (8×4, subject to local limits) |
|
Engine Output |
340 HP – 430 HP (6×4); 380 HP – 540 HP (8×4) |
|
Emission Standards |
Euro II, Euro III, Euro IV, Euro V (dependent on model year and export rules) |
|
Transmission |
10, 12, or 16-speed manual; selective AMT configurations |
|
Axle Ratings |
Front: 7,000 – 9,000 kg; Rear Hub-Reduction: 13,000 – 16,000 kg |
|
Dump Body Volume |
15 cubic meters to 35 cubic meters (U-shape or rectangular) |
|
Plate Thickness |
Floor: 8 mm – 12 mm high-strength steel; Walls: 4 mm – 6 mm |
|
Hydraulic System |
Front-mounted multi-stage heavy-duty ram with PTO gear pump |
|
Chassis Dimensions |
Length: 8,200 – 9,800 mm | Width: 2,490 – 2,550 mm | Height: 3,300 – 3,550 mm |
Is a Used Heavy Rigid Dump Truck Suitable for Your Operation?
A used rigid dump truck can be a practical option when the priority is lower acquisition cost, rapid fleet deployment and straightforward bulk-material transport.
Typical applications include:
Aggregate and quarry material hauling
Sand and gravel transportation
Earthmoving and excavation projects
Road and infrastructure construction
Construction-site material transport
Coal and mineral material transport
Demolition and construction-waste handling
Short- and medium-distance bulk haulage
The right configuration depends more on the working environment than on engine horsepower alone. A 6×4 truck may be appropriate where payload requirements and road access are moderate. An 8×4 configuration can provide a larger payload platform and higher axle capacity for applications requiring greater carrying capacity, subject to local legal axle-load limits.
Available Drive Configurations: 6×4 vs. 8×4 & Selection Guide
6×4 Heavy Rigid Dump Truck
• Chassis Layout: Two driven rear axles.
• Best Suited For: Moderate payload requirements, paved or mixed road networks, urban or confined construction sites, and projects prioritizing tighter turning radiuses and lower operating costs.
• Buying Rule: Choose 6×4 when site access is tight, payload needs are standard, and local axle-load regulations favor a lighter three-axle footprint.
8×4 Heavy Rigid Dump Truck
• Chassis Layout: Two front steering axles and two driven rear axles.
• Best Suited For: High-payload bulk transport, large-scale quarry operations, heavy aggregate hauling, and intensive earthmoving projects.
• Buying Rule: Consider 8×4 when the operation involves massive bulk-material movement and the route/project supports a larger rigid chassis. Always verify local four-axle legal limits before committing.
Dump Body and Hydraulic System
The dump body is a working load-bearing structure, not simply a cargo box. For used equipment, inspect:
Dump Body
Floor wear thickness and side-wall deformation.
Cracks around high-stress pivot areas, weld repairs and corrosion levels.
Tailgate locking mechanism, subframe alignment and evidence of chronic overloading.
Hydraulic System
Hydraulic cylinder leakage, chrome rod scoring and pump pressure operation.
Hydraulic hose flexibility, connection leaks and tipping speed.
Abnormal hydraulic noise and full lifting/lowering cycle execution.
A truck can feature a clean exterior while concealing expensive internal hydraulic or structural degradation. These systems must be verified independently.
Chassis and Structural Condition
Chassis health is the primary dividing line between a profitable used dump truck and an ongoing liability. The inspection should focus on:
Main frame rails, cross members and suspension mounting brackets
Axle mounting zones and dump-body subframe integrity
Welded reinforcements, structural cracks or chassis distortion
Evidence of past accident repairs, heavy frame straightening or chronic overloading
Extra scrutiny is required for units originating from heavy quarries, mines or aggressive earthmoving sites, as low mileage does not rule out severe structural fatigue.
Optional Refurbishment Services Before Export
To reduce deployment friction upon arrival at the destination port, optional pre-export conditioning and refurbishment packages can be arranged based on buyer requirements:
Fluid and filter replacement (engine oil, transmission oil, coolants)
Hydraulic cylinder seal kit replacement or hose renewal
Brake friction material inspection and replacement if required
Cab interior detailing, seat repair and HVAC testing
Chassis rust cleaning and protective undercoating
Loading and Shipping Methods for Used Trucks
To ensure safe international transport, available export shipping methods include:
RORO (Roll-on/Roll-off): The most cost-effective method for drivable heavy trucks, secured directly on vessel decks.
Flat Rack Container: Ideal for trucks requiring specific routing or destination ports without direct RORO vessel calls.
Bulk Cargo Shipping: Deployed for multi-unit fleet shipments.
Complete export documentation, including bills of lading, commercial invoices, packing lists and origin certificates, is coordinated per shipment.
FAQ
Q: What is the difference between a new dump truck and a used rigid dump truck in terms of ROI?
A: A used rigid dump truck significantly lowers initial capital expenditure, allowing contractors and fleet operators to achieve a faster return on investment on projects with defined durations. While new trucks offer long factory warranties, well-maintained used units on established platforms (such as HOWO or SHACMAN) provide comparable operational capability at a fraction of the acquisition cost, provided that mechanical and structural inspections are thoroughly vetted prior to purchase.
Q: Can used dump trucks be modified or repainted to match our fleet corporate identity?
A: Yes. Pre-export preparation services can include cosmetic refurbishment, such as cab repainting to match your corporate color scheme, applying company logos, and replacing worn seat covers or interior trim. These modifications are typically coordinated prior to loading at the port of departure.
Q: How do you verify the mileage and operating hours of a used heavy truck?
A: Verification relies on a combination of digital instrument cluster readings, available electronic control unit (ECU) data logs, physical component wear analysis (such as pedal rubber wear, steering wheel texture, and seat degradation), and historical maintenance records when provided by the previous operator. Cross-referencing these indicators helps establish an accurate assessment of the truck's actual service life.
Q: What happens if a mechanical component fails shortly after the truck arrives at the destination port?
A: Because used commercial vehicles are sold on an as-is inspection basis, post-arrival warranties are generally not standard unless a specific pre-delivery refurbishment contract was agreed upon. To mitigate this risk, buyers receive comprehensive photo and video evidence, cold-start footage, and detailed inspection checklists for approval before shipment is dispatched. Furthermore, sourcing platforms built on common heavy-truck architectures ensure that replacement engine, transmission, and chassis parts remain widely accessible in most international markets.
Q: Are replacement parts readily available for Chinese heavy-truck platforms overseas?
A: Yes. Major Chinese commercial vehicle platforms like HOWO, SHACMAN, and FAW have established global spare parts distribution networks across Africa, the Middle East, Southeast Asia, and South America. Routine service filters, brake linings, suspension bushings, and major powertrain components can typically be sourced locally or shipped rapidly through international logistics channels.
