Container Skeleton Semi-trailer

This is the rear view of a tri-axle container skeletal semi-trailer, offering a clear view of the rear bumper, taillight assembly, reflective markings, and the layout of the main frame and corner castings. The trailer adopts a tri-axle design for even load distribution and high carrying capacity, compatible with various standard containers. Its high-strength steel skeleton balances lightweight design and structural rigidity to meet road transport regulations, while the complete rear safety features effectively ensure driving safety and regulatory compliance.
Send Inquiry
Product Introduction


 tri-axle green Container Skeleton Semi-trailer

Tri Axle Container Skeletal Semi Trailer Technical Specification Table

Parameter Name

Technical Specification

Unit

Remarks

Product Model

Tri Axle 40FT Container Skeletal Semi Trailer

Unit

Standard ISO Container Transport

Product Type

Skeletal Semi Trailer

Unit

For Container Intermodal Transport

Design Lifetime

15

Years

Normal Operation Condition

Max Operating Speed

90

Kilometers Per Hour

Highway Transport Limit

Gradeability

30

Percent

Maximum Climbing Capacity

Turning Radius

8.5

Meters

Minimum Turning Diameter

Overall Length

12400

Millimeters

Standard 40FT Container Adaptation

Overall Width

2500

Millimeters

Comply With Road Transport Width Limit

Overall Height

1550

Millimeters

Without Container Loaded

Ground Clearance

300

Millimeters

Minimum Ground Clearance

Wheel Base

6800

Millimeters

Distance Between Front and Rear Axle Center

Track Width

1840

Millimeters

Distance Between Left and Right Wheel Center

Front Overhang

1600

Millimeters

From Kingpin Center to Front End

Rear Overhang

4000

Millimeters

From Rear Axle Center to Rear End

Curb Weight

6800

Kilograms

Unladen Vehicle Weight

Rated Load Capacity

35000

Kilograms

Maximum Permissible Payload

Gross Vehicle Weight

41800

Kilograms

Maximum Permissible Total Weight

Axle Load Distribution

13400/14200/14200

Kilograms

Front/Middle/Rear Axle Rated Load

Kingpin Load

16000

Kilograms

Maximum Permissible Kingpin Load

Load Distribution Ratio

40/60

Percent

Front/Rear Axle Load Ratio

Axle Quantity

3

Unit

Heavy Duty Semi Trailer Axle

Axle Type

American Style Heavy Duty Axle

Unit

13T Rated Load Per Axle

Brake Size

420x180

Millimeters

Per Axle Brake Drum Size

Wheel Quantity

12

Unit

6 Wheels Per Axle Dual Tire Configuration

Tire Size

12R22.5

Unit

All Steel Radial Truck Tire

Rim Size

9.00x22.5

Unit

Heavy Duty Steel Wheel Rim

Kingpin Type

2 Inch 50#

Unit

Standard SAE J700 Kingpin

Kingpin Height

120

Millimeters

Above Mounting Plate

Landing Gear Type

Heavy Duty Two Speed Landing Gear

Unit

Manual Operation

Landing Gear Load Capacity

28000

Kilograms

Static Load Capacity

Landing Gear Lift Stroke

400

Millimeters

Maximum Lift Distance

Frame Material

High Strength Low Alloy Steel

Unit

Q355B Steel Grade

Main Beam Section

500x140x10

Millimeters

Height/Width/Thickness

Cross Beam Quantity

8

Unit

Reinforced Cross Beam Structure

Side Beam Section

160x80x6

Millimeters

Height/Width/Thickness

Container Lock Quantity

12

Unit

Standard ISO Container Twist Locks

Lock Type

Manual Operated Twist Lock

Unit

With Safety Locking Device

Bumper Type

Heavy Duty Steel Rear Bumper

Unit

Comply With Impact Resistance Standard

Bumper Height

550

Millimeters

Above Ground

Fender Type

Steel Plate Fender

Unit

With Mudguard and Anti Spray Device

Fender Thickness

3

Millimeters

Steel Plate Thickness

Voltage

24

Volts

DC Power Supply

Wiring Harness Type

Waterproof Integrated Wiring Harness

Unit

With Overload Protection

Tail Light Assembly

Full LED Combination Tail Light

Unit

Left and Right Symmetric

Tail Light Function

Stop/Turn/Reverse/Position/Reflector

Unit

Multi Function Integrated

Side Marker Light

LED Side Marker Light

Unit

6 Units Per Side

Reflector Type

Red/White Retro Reflector

Unit

Comply With ECE R48 Standard

License Plate Light

LED License Plate Light

Unit

2 Units At Rear

Connector Type

7 Pin ISO Trailer Connector

Unit

Standard SAE J560 Connector

Battery Box

Steel Waterproof Battery Box

Unit

For 2x12V Battery Installation

Braking System Type

Dual Circuit Air Brake System

Unit

Comply With ECE R13 Standard

Service Brake

Air Operated Drum Brake

Unit

Per Axle Independent Control

Parking Brake

Spring Brake Chamber

Unit

Per Axle Equipped

Emergency Brake

Relay Emergency Valve

Unit

Automatic Brake When Air Pressure Loss

ABS System

4S/3M Anti Lock Braking System

Unit

Comply With ECE R10 Standard

Brake Chamber Type

30/30 Double Diaphragm Chamber

Unit

Per Axle 2 Units

Air Tank Capacity

60

Liters

2 Units Total 120 Liters

Air Compressor Matching

Compatible With Tractor Air Supply

Unit

Minimum 0.7MPa Working Pressure

Brake Adjustment

Automatic Slack Adjuster

Unit

Per Axle Equipped

Suspension Type

Heavy Duty Multi Leaf Spring Suspension

Unit

American Style

Leaf Spring Quantity

10

Unit

Per Axle 10 Pieces

Leaf Spring Thickness

16

Millimeters

Single Leaf Thickness

Leaf Spring Width

90

Millimeters

Spring Width

Shock Absorber

Double Acting Hydraulic Shock Absorber

Unit

Per Axle 2 Units

Stabilizer Bar

Heavy Duty Torsion Stabilizer Bar

Unit

Front and Rear Axle Equipped

Bushing Type

Polyurethane Bushing

Unit

High Wear Resistance

Axle Distance

1300

Millimeters

Distance Between Adjacent Axles

Adaptable Container Size

20FT/40FT/45FT

Unit

Standard ISO Dry Van Container

Container Lock Position

Standard ISO Hole Position

Unit

12 Lock Points For 40FT Container

Max Container Height

2896

Millimeters

Standard High Cube Container Adaptation

Max Container Weight

30480

Kilograms

Maximum Permissible Container Gross Weight

Container Fixation Method

Twist Lock Mechanical Fixation

Unit

With Secondary Safety Lock

Adaptable Container Type

Dry Van/Refrigerated/Open Top

Unit

Standard ISO Container Types

Compliance Standard

GB 7258/GB 1589

Unit

China National Road Vehicle Standard

International Certification

ECE R13/R48/R10

Unit

European Union Standard Certification

Welding Standard

ISO 3834

Unit

International Welding Quality Standard

Surface Treatment

Electrophoretic Coating + Powder Spraying

Unit

Anti Corrosion Treatment

Coating Thickness

80

Micrometers

Minimum Coating Thickness

Salt Spray Resistance

1000

Hours

Neutral Salt Spray Test Result

Noise Emission

Comply With GB 1495

Unit

Noise Emission Standard

Emission Compatibility

Compatible With Euro 3/4/5/6 Tractor

Unit

Emission Standard Adaptation
